2A11 aluminum alloy bar rod

2A11 aluminum alloy is a kind of hard aluminum used earliest, which is generally called standard hard aluminum. It has medium strength, good plasticity in annealing, rigid quenching and thermal state, and can be strengthened by heat treatment. It can be used in quenching and natural aging state. It has good spot welding performance, and has a tendency to crack during gas welding and argon arc welding; Machinability is good in quenching and aging state, but bad in annealing state.



Properties of Henan Chalco 2A11 aluminum alloy bar rod:
Tensile strength σ b (MPA)：≥370
Conditional yield strength σ 0.2 (MPA)：≥215
Elongation δ 5 (％)：≥12
(Note: longitudinal mechanical properties of bar at room temperature, sample size: bar diameter (square bar, hexagonal bar inscribed circle diameter) ≤ 150)
Heat treatment process of Henan Chalco 2A11 aluminum alloy bar rod:
1) Homogenization annealing: heating 480 ~ 495 ℃; Heat preservation for 12 ~ 14h; The furnace is cold.
2) Complete annealing: heating 390 ~ 430 ℃; Holding time 30 ~ 120min; Air cooling.
3) Rapid annealing: heating 350 ~ 370 ℃; The holding time is 30 ~ 120min; Air cooling.
4) Quenching and aging: quenching 495 ~ 510 ℃, water cooling; Artificial aging 155 ~ 165 ℃, 6 ~ 10h, air cooling; Natural aging: 96h at room temperature.
2A11 aluminum alloy status: aluminum and aluminum alloy extruded bars (≤ 150mm, h112, T4 status)
2A11 aluminum alloy bar rods supplied by Henan Chalco are pbar roduced in strict accordance with gb/t3191-2010, gb/t6892-2006, gb/t3190-2008 and other national standards to ensure excellent pbar roduct quality. Pbar roducts can be customized according to customers' special requirements.

Author: Chalco

Chalco Aluminium is specialized in producing and marketing aluminium bar.Our customer service representatives are qualified,knowledgeable aluminum bars experts, Thire industry expertise and professionalism will save you time and money and ensure that you have the best aluminium bars and rods.
