6063-t52 aluminum flat bar

6063 aluminum flat bar contains two main alloying elements, namely magnesium and silicon, which have good processability, excellent weldability, extrudability and electroplating, good corrosion resistance, toughness, easy to light, and upper coating , excellent anodizing effect, is a typical extrusion alloy.



chemical composition

Aluminum Al : Allowance
Silicon Si: 0.20 to 0.6
Copper Cu: ≤0.10
Magnesium Mg: 0.45～0.9
Zinc Zn: ≤0.10
Manganese Mn: ≤0.10
Titanium Ti: ≤0.10
Chromium Cr: ≤0.10
Iron Fe: 0.000 to 0.350
Note: single: ≤0.05; total: ≤0.15
Mechanical properties
Tensile strength σb (MPa): ≥205
Conditional yield strength σ0.2 (MPa): ≥170
Elongation δ5 (%): ≥9
Temper: T5, T6, T52
Note: Longitudinal mechanical properties of bar at room temperature

Sample size: bar diameter (square bar, hexagonal bar inscribed circle diameter) ≤ 25
The main purpose of 6063 aluminum flat bar
1. The application of 6063 aluminum flat bar is very good, and can be used in decoration, packaging, construction, transportation, electronics and other industries;
2. In transportation, 6063 aluminum flat bar is used for car body structural parts of automobiles, subway vehicles, railway passenger cars, high-speed passenger cars, doors and windows, shelves, automobile engine parts, air conditioners, radiators, body panels, wheel hubs and marine materials ;
3. Packaging 6063 aluminum flat bar can be used for all-aluminum pop-top cans, mainly in the form of sheet and foil as metal packaging materials to make cans, lids, bottles, barrels, and packaging foils;
